Energy-Saving and Environmentally Friendly Air-Source Heat Pump Isatis Drying Room

The Isatis Drying Room utilizes 75mm thick rock wool sandwich panels with a surface layer of color-coated steel plates. These panels are formed using an automated continuous forming machine and then bonded with a high-strength adhesive. Because both the color-coated steel plates and the core rock wool are non-combustible, they offer excellent fire resistance and thermal insulation properties, capable of withstanding temperatures ranging from 100°C to 180°C.

Drying Principle of the Isatis Drying Room Equipment:

The Isatis Drying Room operates based on the reverse Carnot cycle. Using a small amount of electrical energy, the compressor converts the working fluid through an expansion valve, where it evaporates into a gas in the evaporator. The evaporator absorbs a significant amount of heat from the air. The gaseous working fluid is compressed by the compressor into a high-temperature, high-pressure gas, which then enters the condenser, releasing heat and heating the drying medium. This continuous heating cycle can heat the drying medium to a temperature of 40°C to 85°C. Compared to electric dryers, this system saves 35%-40% of electrical energy.

Advantages of the Isatis Root Drying Room:

1. Excellent drying performance, uniform air distribution within the room, and adjustable temperature ensure uniform moisture content and ideal color of dried herbs.

2. The equipment and drying room are completely isolated and operated separately, preventing the dried herbs from coming into contact with sulfur dioxide gas, further eliminating the risk of fire.

3. The equipment is available with bottom, side, and top ventilation options, allowing for customization based on the specific herbs and guest room requirements. It is equipped with a powerful airflow control system to ensure adequate airflow throughout the drying room.

4. Loading carts and sieve baskets can be added to meet diverse customer requirements.

5. Energy-saving and environmentally friendly, it uses 40% less electricity than electric drying machines.
