Gastrodia Elata Dryer

Posted at: 2016 / 12 / 01 by: Admin views:

Gastrodia Elata Dryer

Working principle:
        Our gastrodia elata drying machine is using inverse cano principle, absorbing heat air and transferring them to the drying chamber to realize the increase of temperature in the dryer. Our gastrodia elata dryer machine is composed of compressor, heat exchanger, flow controller and heat absorber, and these devices form a cycling system (main drying device and drying chamber). Under the action of compressor, the refrigerant will be flowing circulating in this system. It will finish the process of pressure rising and temperature rising in the compressor (temperature can be up to 95℃), then release high temperature source to heat the air in the chamber, and at the same time, it will be cooled and translated into liquid. When it runs out the machine, the liqud will aborb hot air quickly and be tanslated to gas again. At the same time, the temperature will be dropped to -20~-30℃, and the heat absorber will transfer the heat source to refrigerant. And the refrigerant tranport the heating source from the air to drying chamber constantly and circularly to heat the air temperature in the chamber.

Gastrodia Elata Dryer

Gastrodia Elata Dryer

The system composition:
        1. Main device (heating system): use less electrical energy to absorb the heat from the air for drying gastrodia elata.
        2. Drying chamber: it is used for loading materials and for keeping temperature and avoiding heat losses.
        3. Wind/air circulation system: to take the heat to full of the drying chamber and improve the temperature, and to take away the water evaporated from gastrodia elata.
        4. Dehumidifying system: drain out the water in the chamber to achieve the purpose of drying.
        5. Waste heat recovery system: the gastrodia elata drying equipment has three waste heat recovery systems, which greatly lower the loss of heat.
        6. Drainage system: discharge the condensate water to outside to avoid the increasing humidity of the chamber.
        7. Programmable intelligent control system: automatically adjust temperature, humidity, drying temperature, and intelligent operation according to the most appropriate drying process curve.
        8. Warning system: to set warning parameters based on time, temperature, humidity, etc. according to users requirements.

Gastrodia Elata Dryer

Model selection:
        1. 3P gastrodia elata dryer machine can adapt about 15 CBM chamber, and it will consume 3 degree electric power per hour.
        2. 6P gastrodia elata dryer can adapt 25 CBM drying chamber, and it will consume 6 degrees electric power per hour.
        3. 10P gastrodia elata dryer can adapt 40 CBM drying chamber, and it will consume 12 degrees electric power per hour.


If you are interested in our products , please send inquiry to our email:Alisa@lantianmachine.com
