Garlic Slice Mesh Belt Dryer

The garlic slice mesh belt dryer is a continuous drying machine for batch production. It is used to dry highly permeable materials in flake, strip, or granular forms. It is particularly suitable for materials with high moisture content, such as dehydrated vegetables, catalysts, and Chinese herbal medicine slices, where high temperatures are not tolerated. Because the machine is intelligent, it can adjust and precisely control parameters such as temperature, humidity, and drying time. This series of dryers offers fast drying speeds, high evaporation rates, and excellent product quality. Pasty materials such as dehydrated filter cakes require granulation or strip formation before drying.

The garlic slice mesh belt dryer is suitable for large-scale production of difficult-to-dry materials. Its compact structure and small footprint make it easy to operate, maintain, and operate stably. It can be designed with different hot air circulation drying modes based on the drying characteristics of the material. It is an extension and improvement of the hot air circulation oven and is widely used in the metallurgical additive, chemical, food, and packaging industries. With technological advancements and the increasing technical content of its products, the garlic slice mesh belt dryer now meets the requirements of large-scale, diversified, centralized, and continuous production. It offers high efficiency, energy saving, high output, fast results, excellent hygiene, and easy management.

The garlic slice mesh belt dryer's main principle is to evenly spread the material on a mesh belt. A transmission mechanism pulls the material through the dryer, rotating it from top to bottom. Hot air flows through the material from bottom to top, and excess water vapor is discharged through dehumidification holes, achieving the desired drying effect. The mesh belt is made of 304 food-grade stainless steel. The housing is constructed from standard sections. To save space, the mesh belt dryer can be configured in multiple layers. Common options include two-chamber, three-layer, and two-chamber, five-layer configurations, with lengths ranging from 6 to 40 meters and effective widths ranging from 0.6 to 3.0 meters.

The main frame of the garlic slice mesh belt dryer is made of painted or stainless steel, and the door panels are made of stainless steel, color-coated steel, or polyurethane. Internal components are made of standard and high-end materials, and the internal mesh belt is all 304 food-grade stainless steel.
