Vileplume Dryer

The vileplume:
        The vileplume can be as vegetable and tea, and it is a kind of worthy natural health food. But because the fresh flowers contain much more than 86% moisture, which is unfavorable for storage, transportation and processing, except some are fresh eaten, we can process the vileplume to dry. A lot of dried vileplumes available in the market are dark color, poor quality, moldy easily, sulfur smoked too much, which lack of food safty guarantee. But Gongyi Lantian Machanical Plant supply a new kind of vileplume dryer that can dry the fresh vileplume to good quality.

Introduction of vileplume drying machine:
        The Lantian brand vileplume drying machine is a kind of environmental protection and energy saving drying equipment. During the drying process, there is no harmful emissions discharging, no smoke or flame, and the temperature and humidity can be adjusted according the raw material property. Our vileplume drying machine is in high intelligent, there is no need the worker supervise during drying process, and after finish drying or the temperature reach the fixed degree, the vileplume dryer machine will stop working automatically. Our vileplume dryer, under the condition of common temperature and pressure, has a biggest advantage that is saving energy. It can save 50% energy than the infrared electric heating device, save 40% energy than oil burning dryer, save 20-30% than the coal burning dryer. And in the process of drying, the vileplume drying machine can produce cold air, and the cold air will be sent to the chamber to improve the working environment.

The model selection of vileplume drying equipment:
        1. 3P vileplume dryer can adapt about 15 CBM chamber, and it will consume 3 degree electric power per hour.
        2. 6P dryer can adapt 25 CBM drying chamber, and it will consume 6 degrees electric power per hour.
        3. 10P dryer can adapt 40 CBM drying chamber, and it will consume 12 degrees electric power per hour.

The processing technology of vileplume drying equipment:
        1. Picking the vileplume.
        Pick the vileplume, then process them immediately. Becuase of the high moisture of vileplume stem, we need to cut the vileplume to 4-6 pieces from stem to bud befroe drying, which can reduce the drying time, improve the drying efficiency and keep the buds consistent color.
        2. Put the vileplume into chamber for drying.
        Put the vileplume uniform, no overlap, no overstocked in case of affacting the drying quality. We put the vileplume on the trays and then put the trays onto the carts. We push the carts into chamber for drying.
        3. Quality inspection.
        After drying 25-30 hours, we can open the chamber to inspect whether is dried vileplume is qualified. We can press the stem of vileplume, if the stem is hard, it means the drying is qualified. If the stem is soft, we need to go on drying. The qualified dried vileplume should be good smell the same with the pitaya, complete flower, less than 12% moisture content and natural color and luster.

The features of vileplume drying equipment:
        1. Vileplume drying machine is an intelligent equipment, a coalition of dehumidification, heating, cooling, exhausing and ventilation, which is a energy conservation and emission reduction drying equipoment.
        2. Using double desiccant dehumidification technology of heat transfer and dehumidification, and it greatly improve the dehumidifying performace rate, and its energy saving effects is obvious.
        3. Out vileplume dryer break through the traditional dehumidifier and normal heat drying machine, and it solve the technical problems of poor dehumidifying performance of traditional drying machine.
        4. Unique design of air-exhausting and heat-recovering system to reduce the heat loss, and make the dryer with better comprehensive energy saving performance.
        5. Advanced fresh air transferring and dehumidification function which can ensure using the fresh air to dry, suitable for strict drying process.
        6. Energy saving, environmental protection and high intelligent drying equipment, and during drying process, there is no harmful emission discharging, no smoke or flame, and the temerature and humidity can be adjusted according to the raw material properties.
        7. Our vileplume drying machine is in high intelligent, there is no need the worker supervise during drying process, and after finish drying or the temperature reach the fixed degree, the vileplume dryer will stop working automatically. Our vileplume dryer, under the condition of common temperature and pressure, has a biggest advantage that is saving energy. It can save 50% energy than the infrared electric heating device, save 40% energy than oil burning dryer, save 20-30% than the coal burning dryer. And in the process of drying, the vileplume drying machine can produce cold air, and the cold air will be sent to the chamber to improve the working environment.
        8. Easy installation, convenient assembly and disassembly, small cover space, and can be installed indoor or outdoor.
        9. High efficiency and energy saving. Our vileplume drying machine just consume a little of electric energy, and it will absorb a large quantity of heat from the outside air. Its consumption is just 1/4 of other electric heating dryer, and compared with the dryer of burning coal, gas, oil, our this kind of dryer can save about 60% operation cost.
        10. Environmental protection and no pollution. During drying process, our vileplume drying equipment has no any combustion or emission, and it is a kind of sustainable development and environment-friendly dryer.
        11. Safe and reliable operation. Durning the whole system operation, there is no flammable, explosive, toxic, short circuit and other risk which may exist in traditional dryer. Our vileplume dryer is a absolutely safe and reliable semi-closed drying equipment.
