Ginger dryer

Introduction of ginger slice dryer:
        Ginger is usually used as season in meat, seafood, rice, tofu, fruit, soup, etc. The fresh ginger will be easily loss nutrient and can’t be stacked for long time, otherwise, they will decay easily.
        Ginger drying process is an very important process and also is a biggest energy consumption process. The almost traditional ginger dryers are gas dryer, coal dryer, oil burning dryer which will have big pollution, high cost operation. With the low carbon energy saving trend of promotion, study a new type of dryer is very urgent. While, our ginger drying machine, compared with the traditional dryer, has remarkable energy saving effect and good dried products. Also, the ginger dryer is using intelligent control technology, built-in various drying process, which not only save a large manpower cost, also save time.

The ginger dryer structure:
        1. Heating device.
        2. Heat preservation chamber.
        3. Hot air circulation device.
        4. Automatic dehumidifying device.
        5. Intelligent control device.

The principle:
        Our ginger drying equipment is using inverse cano principle, absorbing heat air and transferring them to the drying chamber to realize the increase of temperature in the dryer. Our ginger dryer is composed of compressor, heat exchanger, flow controller and heat absorber, and these devices form a cycling system (main drying device and drying chamber). Under the action of compressor, the refrigerant will be flowing circulating in this system. It will finish the process of pressure rising and temperature rising in the compressor (temperature can be up to 95℃), then release high temperature source to heat the air in the chamber, and at the same time, it will be cooled and translated into liquid. When it runs out the machine, the liqud will aborb hot air quickly and be tanslated to gas again. At the same time, the temperature will be dropped to 20-30℃, and the heat absorber will transfer the heat source to refrigerant. And the refrigerant tranport the heating source from the air to drying chamber constantly and circularly to heat the air temperature in the chamber.

The characteristics of ginger dryer:
        1. High efficiency and energy saving. The turmeric drying machine is using small quantity of electric energy to absorb the heat in the outside air to realize the drying purpose.
        2. Advanced and intelligent. No need manpower supervise during drying process, automatic drying and good drying efficiency.
        3. Stable performance. Good drying efficiency, lower power consumption, and big capacity.
        4. Multi-function. Lantian brand ginger dryer has the functions of drying, dehumidifying, air flowing, refrigerating, heat recovering, etc. to achieve diversification.
