Rose Dryer

Introduction of rose dryer:
        Our rose drying machine is using inverse cano principle, absorbing heat air and transferring them to the drying chamber to realize the increase of temperature in the dryer. Our rose dryer is composed of compressor, heat exchanger, flow controller and heat absorber, and these devices form a cycling system (main drying device and drying chamber). Under the action of compressor, the refrigerant will be flowing circulating in this system. It will finish the process of pressure rising and temperature rising in the compressor (temperature can be up to 85℃), then release high temperature source to heat the air in the chamber, and at the same time, it will be cooled and translated into liquid. When it runs out the rose drying machine, the liqud will aborb hot air quickly and be tanslated to gas again. At the same time, the temperature will be dropped to -20~-30℃, and the heat absorber will transfer the heat source to refrigerant. And the refrigerant tranport the heating source from the air to drying chamber constantly and circularly to heat the air temperature in the chamber.
        The rose drying machine is composed of: 1. Heating device and moisture reducing device. 2. Heat preservation chamber. 3. Hot air circulation system. 4. Intelligent controlling system. The heating device is for generatoring the hot air, and circulation system is to ensure the temperature and inside airflow uniform. While, the intelligent controlly system is to make the whole drying process with constant temperature and constant humidity to ensure the drying quality.

The model selection of rose drying equipment:
        1. 3P rose dryer machine can adapt about 15 CBM chamber, and it will consume 3 degree electric power per hour.
        2. 6P flower drying machine can adapt 25 CBM drying chamber, and it will consume 6 degrees electric power per hour.
        3. 10P dryer can adapt 40 CBM drying chamber, and it will consume 12 degrees electric power per hour.
The features of rose drying machine:
        1. Adopt closed circulating drying method, save operation cost, no wastes emission, no noise, environmental protection.
        2. Using our rose dryer will expand the industrial drying application, and its drying efficiency can save 30% energy.
        3. Middle or low temperature drying method (15-50℃/60℃/80℃), which close to the nutural drying. The dried good will in good quality, good color and lustre, high level products, no pollution, which is more in line with environmental protection and health requirements.
        4. PLC touching screen automatic control system, stable performance, easy operation, programmable control method, which can set different drying curve to meet different materials drying ways.
        5. Short drying time and good sealing property.
        6. High quality parts for this rose drying machine to ensure the fungus drying equipment performance.
        7. Set up multiple security pretection function: the phase sequence protection, default phase protection, overload protection, high voltage protection, low voltage protection, etc.
        8. Nice appearance design, taking small area space.
