Fungus Drying Machine

The fungus condition:
        The fungus moisture is usually 80-90%, and they will easily go bad if store them under commor temperature, and also they are not conducive to transported and sold. So except sell some fresh fungus, the other fungus will be processed to dry fungus, which will be easy to storage and transport to meet the requirements of home and overseas. The purpose of drying fungus is making use of heating and dehumidifying to reduce the water content of fungus, then to make the fungus body solids increased to the point which can’t be used. And at the same time, the enzymes activity of fungus will be restrained, which make the fungus storaged longer. The good quality dried fungus should be fragrance smell, fresh color, round shape, smooth furface, upright gill, and less than 13% water content.
        The fungus drying process need temperature increasing fast, good heat preservation effect, full matching machine.

Lantian brand fungus drying machine contains:
        1. Main machine: located on the same flat ground with the drying chamber.
        2. Fans: equipped according to the materials and the chamber size.
        3. Dehumidifying fan.
        4. Air flow: designed according to the materials placement.
The loading devices for fungus drying machine:
        The loading devices are mainly trays and carts which have to be designed strong, light and durable use.
        1. Loading trays: it is for loading the fresh fungus. The shape of trays can be rectangular or square. The length can be 100cm, width 60cm, and height 4-5cm. It is better to make the trays by using stainless steel, and bottom mesh can be made according the raw materials, and the mesh can’t be too dense, otherwise it will effect the air flow.
        2. Loading carts: it is for loading the trays. The carts will be usualy designed for 8-10 layers, and each layer distance is 14cm, and bottom distance from ground is about 30cm. The size of carts should be matched with each other.

The advantages of fungus drying equipment:
        1. Energy saving and high efficiency. The operation cost of our fungus dryer is just 40% of oil burning dryer, 60% of coal dryer, and 30% of other electric heating dryer.
        2. Security and environmetal protection. Our fungus drying equipment is absolute safe (electric seperation technology), and zero wastes emission.
        3. Good drying quality. During the process of drying, the fungus will not deform, crack, change color or go bad, also they will be fully dried, less loss of nutrients, good rehydration, longer storage, and our fungus drying machine is much better to protect the fungus’ color, tastes, smell, shape and others.
        4. Real constant temperature drying. No need to discharge the high temperatur air to outside, because the high temperature air will be circulated.

The features of fungus drying machine:
        1. Adopt closed circulating drying method, save operation cost, no wastes emission, no noise, environmental protection.
        2. Using our fungus dryer will expand the industrial drying application, and its drying efficiency can save 30% energy.
        3. Middle or low temperature drying method (15-50℃/60℃/80℃), which close to the nutural drying. The dried good will in good quality, good color and lustre, high level products, no pollution, which is more in line with environmental protection and health requirements.
        4. PLC touching screen automatic control system, stable performance, easy operation, programmable control method, which can set different drying curve to meet different materials drying ways.
        5. Short drying time and good sealing property.
        6. High quality parts for this fungus drying machine to ensure the fungus drying equipment performance.
        7. Set up multiple security pretection function: the phase sequence protection, default phase protection, overload protection, high voltage protection, low voltage protection, etc.
        8. Nice appearance design, taking small area space.
