Chilli dryer

Posted at: 2016 / 12 / 02 by: Admin views:

Chilli dryer

        The pepper is a very popular vegetable, and its tastes is unique. It has rich nutrition, vitamin content is high. The red pigment in the pepper is widely used in food, beverage, medicine, cosmetics and other fields. The fresh peppers or chilis have much water, and they can’t be easily stored, so we need to dry them at the harvest time. Lantian brand pepper dryer is combined with drying and dehumidifying system, and it has the features of high drying quality, low drying cost, short drying time and big drying capacity.

Chilli dryer

The introduction:
        Lantian brand pepper drying machine is composed of drying chamber, heating device, moisture exhausting and air recycling device, and intelligent control system. Pepper dryer is using and absorbing the heat of air outside of chamber, and transferring them into the chamber to improve the inside temperature to dry the betel nuts. Among processing, the heating device absorb the heat from air ourside, or recycle the waste heat in the process of drying, through the action of compressor, it transfer the heat into drying chamber. The hot wind moisture exhausting process or condensation draining process will take the water out, and final realize the drying purpose continuously.

 Chilli dryer

The drying process:
        1. The stacking thickness of drying chili.
        The chilli stacking thickness is usually 20-30cm. If too thin, the air permeability is good, wind resistance is small, although it is conducive to heat exchange, but the hot air will has short time to contact with chili, then the heat utilization rate is low. If the stacking thickness is too thick, the resistance will increase, the hot air can’t penetrate the chili layer, then the drying effect is not good.
        2. Temperature selection.
        The moisture content of fresh pepper is very high, which is usually 75-85%. Use 40-60℃ hot air to dry, and gas relative humidity is below 70% at first, and it willl be below 52% after 5 hours. After 12 hours, the waste gas relative humidity is less than 40%. Thus the pepper humidity reducing speed is under the control of inside moisture transferring time. Therefore, the pepper drying work depends on the pepper temperature itself, not depends on the the wet platoon ability. To ensure the dried pepper nutrients are not affected after drying, and improve the drying efficiency, we can control the temperature of chili drying machine with better 60-80℃.
        3. The piecewise drying method of pepper drying equipment.
        Piecewise drying is a superior drying method at present. The pepper water content is 75-85%, we can dry them to 50% at first step, and then for second drying process. During first drying process, the chili will has obvious softening and expansion. The pepper oil will penetrate to surface, and dried pepper will has same color with fresh pepper. If without the first step, the drying time will be very very long.

Chilli dryer

Chilli dryer

The features:
        1. Easy installation and demolition, small covering space, and can be installed in the indoor or outdoor.
        2. High efficiency and energy saving. Our red pepper drying machine can absorb much heat source from the air, and its electric consumtion is just 1/3-1/4 of other heater. And compared with coal dryer, gas fuel dryer, and the old type dryer, our chilli dryer can save 75% operation cost.
        3. No pollution and environmental protection. Our chilli drying equipment, no any combustion or emissions, completely meet the food hygienic standard, is a kind of sustainable development and environmental friendly drying equipment.
        4. Running safely and reliably. Compared with the traditional drying equipments (coal dryer, gas fuel dryer, or other elctric heater), our pepper dryer will never has the risks of flammability, explosive, toxic, short circuit, etc. And it is a absolutely safe and reliable closed drying device.
        5. Long using life and low maintenance cost. Our chilli drying machine is developped from the traditional drying machine, so our this new type spice drying machine has mature technology, stable performance, reliable and long lifetime.
        6. Comportable, convenient, and high automatic and intelligent.
        7. Wide application and not affected by weather. Our pepper dryer machine can be widely used in food, chamical, pharmaceutical, paper, leather, wood, agricultural and sideline products, etc.


If you are interested in our products , please send inquiry to our email:Alisa@lantianmachine.com
